WRS Electric Leakage Protection Device is a protective device specially designed for high-voltage circuits. It can effectively prevent the damage of surge voltage in high-voltage power grid to electrical equipment. It can respond quickly in extreme cases to protect the safety of equipment.

Switching and isolation.

Overload and short circuit protection.

Protection against the effects of sinusoidal alternation earth fault currents.

Indirect and direct contacts protection.

Protection against fire hazard caused by insulation faults.

Technical Parameters

Part No	Description	Box Qty
WRS106B-140B/030	Single Module 6Amps-40Amps B Curve 30mA	50
WRS106B-140B/100	Single Module 6Amps-40Amps B Curve 100mA	50
WRS106C-140B/030	Single Module 6Amps-40Amps C Curve 30mA	50
WRS106C-140B/100	Single Module 6Amps-40Amps C Curve 100mA	50

Product Features

The WRS Electric Leakage Protection Device is designed to provide advanced safety for electrical systems by detecting and preventing electric leakage. Ideal for residential, commercial, and industrial applications, this device helps minimize the risk of electric shock and electrical fires by continuously monitoring for residual currents. Its compact design allows for easy installation in standard electrical panels, ensuring efficient integration into existing systems. The WRS device features a user-friendly test button for regular functionality checks and a clear indicator for operational status. Compliant with national electrical safety standards, it enhances overall safety and reliability. With durable construction and responsive performance, the WRS Electric Leakage Protection Device is an essential safeguard for protecting both people and property from electrical hazards.

Rated current (In): 6A, 10A, 16A, 20A, 25A, 32A, 40A.

Rated voltage (Ue): 230V AC,

Breaking capacity (lcn): 6kA.

Rated residual current: 30mA, 100mA.

Tripping characteristic: B.

Electrical endurance: 4000 cycles.

Mechanicalendurance: 100000 cycles

Complies with BS EN 61009-1.
